SC133 Hall Switch Element Speed Meter All Poles Micro Switch Hall Effect Sensor

• SC133 Hall switch element Speed meter all poles Hall effect switch used in DC brushless motors, mobile phones and notebook computers with ISO9001, Rohs etc certification and high lifespan
• Output terminal voltage:-0.5-60
• Product name:Hall sensor Switch
• Output terminal current sink:ISINK 0-50
• Material::chip
• Operating ambient temperature:-40+150TA
• Maximum junction temperature:-55 +165
• Power supply voltage:-40 +60
• Item::Vertical mounted PCB
• Voltage::2.5-24v
• Keywords:Hall sensor
• Whether the smart:yes
• Place of Origin:CN;GUA
• Certification:ROHS
• Brand Name:BeeLee
• Model Number:SC1133
• Max. Current:<20mA
• Max. Voltage:<12V

The SC113X Hall-Effect switch series is monolithic integrated circuits with tighter magnetic
specifications, designed to operate continuously over extended temperatures to +150℃, and are
more stable with both temperature and supply voltage changes. The negative compensation slope
is optimized to match the negative temperature coefficient of low cost magnets.

01.The SC113X Hall-Effect switch series is monolithic integrated circuits with tighter magnetic
specifications, designed to operate continuously over extended temperatures to +150℃, and are
more stable with both temperature and supply voltage changes. The negative compensation slope
is optimized to match the negative temperature coefficient of low cost magnets.
02.Each device includes a voltage regulator for operation with supply voltages of 3.8 to 40V volts,
quadratic Hall-voltage generator, temperature compensation circuitry, small-signal amplifier,
Schmitt trigger, and an open-collector output to sink up to 40mA.
