Marine Waterproof Laser Etched 24V 20A On/Off SPST 5 PIN Two Bar Illuminated Carling Bus 12volt Rocker Switch For Auto

BL-CX-KCD1-101

minimum order

1 piece

Quantity:

Contact Now

add to cart

Certification:RoHS
Whether the smart:NO
Place of Origin:Guangdong, China
Brand Name:beelee
Model Number:BL-CX-KCD1-101
Max. Current:24V
Max. Voltage:250V
Mechanical Life:10000cycles
CONTACT RESISTANCE:50mΩ max
INSULATION RESISTANCE:100MΩmin
Rated current:6A-10A
Voltage:250V/125V
Dielectric strength (between electrodes):≥1500V 5S
Electrical life:10000

01.Single pole and single throw: 1 moving contact and 1 stationary contact. Only one channel

02.Single pole and double throw: 1 moving contact and 2 static contacts (the static contacts on both sides can be connected respectively)

03.Double-pole single-throw 2 moving contacts and 2 static contacts, with 2 channels

04.Double-pole double-throw has 2 moving contacts and 4 static contacts, and there are 4 channels that can connect the 2 static contacts on both sides respectively)

1	Item	Condition
2	Rating	6A 250V/10A 125V
3	Insulation Resistance	≥100mΩ
4	Contact Resistance	≤50mΩ
5	Dielectric strength	≥1500V 5S
7	Electrical life	10000cycles
